Best Practices for HPA/HPW Construction Presented by: Rob Starr, - PowerPoint PPT Presentation

Best Practices for HPA/HPW Construction Presented by: Rob Starr, Residential Training Manager, ConSol About ConSol Energy consulting local, state and national Energy analysis and design Mechanical engineering - focused on


  1. Best Practices for HPA/HPW Construction Presented by: Rob Starr, Residential Training Manager, ConSol

  2. About ConSol  Energy consulting – local, state and national  Energy analysis and design  Mechanical engineering - focused on hot and dry  Inspections and diagnostics – residential and commercial  Auditor for retrofit programs for Central Valley, CA  One of two CEC certified registries for CA Energy Code  Residential  California - Chair, CBIA Energy and Codes Committee  Governor’s Advisory Board - CALGreen  NAHB – Energy and Green Subcommittees, Energy Efficient Buildings Tax Credit Working Groups  NGBS 2015 ICC-700 Consensus Committee  Commercial  California Building Properties Association  BOMA California, NAOIP, ICSC, IREM, RILA 3

  3. 2016 Title 24 Building Efficiency Standards • Five significant changes went into effect on January 1, 2017 – High Performance Attics (HPA) – High Performance Walls (HPW) – 0.82 EF Tankless Water Heaters – High Efficacy lighting – Solar Trade-Off 4

  4. High Performance Attics (HPA) 5

  5. What are the Prescriptive Requirements for High Performance Attics? 6

  6. OPTION A – ABOVE ROOF DECK  Requires Insulation Above the Roof Rafters, directly in contact with the roof deck  R6 required when an air gap is present  R8 required when no air gap is present  Requires Radiant Barrier to be installed  Requires R38 insulation above the ceiling lid  Requires a ventilated attic 7

  7. DETAIL OF INSULATION ABOVE THE ROOF DECK 8

  8. DETAIL OF INSULATION ABOVE ROOF RAFTER

  9. OPTION B – BELOW ROOF DECK  Requires Insulation Below the Roof Deck, Installed between the roof rafters  R13 required when an air gap is present  R18 required when no air gap is present  No Radiant Barrier to be installed  Requires R38 insulation above the ceiling lid  Requires a ventilated attic 10

  10. BELOW ROOF DECK WITH AIR GAP

  11. DETAIL OF INSULATION BELOW DECK 12

  12. DETAIL OF INSULATION BELOW DECK 13

  13. OPTION C – DUCTS IN CONDITIONED SPACE  Requires air handler and ducts to be in conditioned space  Requires radiant barrier to be installed – CZ dependent  Requires R30/38 installed at ceiling – CZ dependent  Requires a ventilated attic 14

  14. DETAIL OF DUCTS IN CONDITIONED SPACE 15

  15. DETAIL OF DUCTS IN CONDITIONED SPACE 16

  16. DETAIL OF DUCTS IN CONDITIONED SPACE 17

  17. PERFORMANCE OPTION –SEALED UNVENTED  Requires complete air sealing between attic and exterior  Requires minimum insulation levels at underside of roof deck  Does not require radiant barrier  Does not require insulation at ceiling  Does not require venting  Does not qualify for ducts in conditioned space 18

  18. DETAIL OF SEALED UNVENTED ATTIC 19

  19. High Performance Walls (HPW) 20

  20. What is a High Performance Wall? 21

  21. U FACTOR TABLES FOR 16” OC 22

  22. U FACTOR TABLES FOR 24” OC 23

  23. High Performance Walls

  24. High Performance Walls

  25. Window Detail – Wood Buck 26

  26. Window Detail – Thermal Buck 27

  27. Window Detail – No Buck 28

  28. Window Detail – With Wood Buck 29

  29. WATERPROOFING WHERE RIGID SHEATHING IS WATER BARRIER 30

  30. Resources www.wisewarehouse.org HPA Protocol Reference Manual HPW Protocol Reference Manual HPW/HPW Product and Strategy Assessment Manufacturer Specific Installation Guides 31

  31. Thank you. Presenter: Rob Starr, Residential Training Manager, ConSol For more information on WISE Contact: Dan Krekelberg, Program Manager– info@wisewarehouse.org
