Anomaly Detection Algorithms for Malware Traffic Analysis using Tamper Resistant Features Dr. Patrick McDaniel Berkay Celik Fall 2015

‣ Introduction ‣ Motivation ‣ Related Work ‣ Data ‣ Approach ‣ Experimental Results ‣ Comparison with Previous Work ‣ Conclusion and Discussion ‣ References 2 Page

Malware Infection Image credit: http://www.vblaze.com / 3 Page

Malware/Legitimate Communication Packet Packet Do features extracted from packet headers discriminate legitimate applications from malware traffic ? How many packets should be aggregated for feature • extraction? Which feature subset should be used for detection? • 4 Page

Goal: To analyze and detect the network-level behavior of malware traffic after blending into the normal traffic: ‣ Focus on detecting malware heartbeat traffic ‣ Features should be tamper resistant (i.e., not easy to fool such as port numbers or flags in packet headers) ‣ Malware traffic is rare, evaluation of anomaly detection algorithms 5 Page

Related Work Current state of the art • Systems based on known signatures: Well studied, a drawback of these systems is not detecting unknown malware traffic • Payload inspection: Vulnerable to privacy issues, payload encryption and limitations in processing high- speed (multigigabit) networks • Feature representation: Drawbacks in selecting “tamper - proof” features such as using port numbers, payload information, protocol specific information and unrealistic malware traffic features when modelling the traffic • Supervised classification algorithms: The requirement of targeted anomalous samples is a disadvantage of these approaches 6 Page

Dataset Malware Traffic Legitimate Traffic, 3513X13 instances 7753 x13 (as a total 16 different instances malware families) ‣ Legitimate Traffic features traces of a small scale organization network recorded at University of Twente with around 35 employees and over Image credit: http://www.vblaze.com/ 100 students 7 Page

Feature space (13 features, all continuous): Flow duration: Difference between last packet time and first • packet time Count of Payload (+): The count of all the packets with at • least a byte of data payload Min data size (+): Minimum payload size observed • Mean of bytes (-): Data bytes divided by the total number of • packets Initial Data Length (*): The total number of bytes sent in initial • window RTT samples (*): Total number of RTT samples found in total • packets Median and Variance of bytes (+): Median and variance of • total packet bytes IP ratio(*): Ratio between the maximum packet size and • minimum packet size Goodput(*): Total number of frame bytes divided flow • duration 8 Page

Feature selection: These papers are the guidelines for the feature selection process: Wei Li, Marco Canini, Andrew W Moore, and Raffaele Bolla. • Efficient application identification and the temporal and spatial stability of classification schema, Computer Networks, 2009 A. Moore, D. Zuev, and M. Crogan. Discriminators for use in • flow based classification . Queen Mary and Westfield College, Department of Computer Science, 2005 Terry Nelms, Roberto Perdisci, and Mustaque Ahamad. • Execscent: Mining for new C&C domains in live networks with adaptive control protocol templates. In USENIX Security ,2013 9 Page

Approach Steps to achieve the goal Overview of Framework 10 Page

Approach Steps to achieve the goal One-class support vector machine (OCSVM) • The distance to the kth nearest neighbor (k-NN) • K-means clustering by finding the distance from data to the • nearest cluster centre Least squares anomaly detection (LSAD) based on the least • squares probabilistic classifier Image from official Scikit-learn, One-class SVM 11 Page

Approach Evaluation Metrics • AUC (Area Under Curve) • ROC curve when necessary • Further experiments for analysis of malware traffic Steps to achieve the goal • Confusion matrix • False positive and false negative counts • Interpretation of PCA and K-means clustering 12 Page

Experimental Setup: • Hyper parameters are set using the subset of the training set • Stratified k-fold cross validation (k is selected depending on the malware traffic Steps to achieve the goal size) or random sampling is applied depending on the number of malware instances • A paired t-test with significance level 0.05 to report the differences of each algorithms' AUC values 13 Page

Experimental Results Steps to achieve the goal 14 Page

Experimental Results: Steps to achieve the goal (More details of ROC curve for each fold is given in report) • Avg. ROC plots the percentage of correctly classified malicious samples (true positive rate) against the percentage of legitimate samples falsely classified as malicious (false positive rate) 15 Page

Experimental Results: Steps to achieve the goal Kaiten vs Neris malware (More details of ROC curve for each fold is given in report) • ROC plots with cross validation the percentage of correctly classified malicious samples (true positive rate) against the percentage of legitimate samples falsely classified as malicious (false positive rate) 16 Page

Lessons Learned from initial results: • No single algorithm performs better than others • Detection Results decrease with the recent evolution of malware families e.g., Zeus V1 Steps to achieve the goal to Zeus V2 • Recent malware traffic gets stealthy, and evades the detection (disguising traffic) 17 Page

Understanding source of false negatives and false positives: Number of legitimate HTTP(S) flows classified as malware Steps to achieve the goal Number of malware flows classified as legitimate HTTP(S) • Mean Values, std is in range +/- 0.53 for all families • Port numbers as a ground truth labels • C4.5 algorithm for classification 18 Page

Detailed Analysis: Steps to achieve the goal Confusion Matrix after cross validation Base Classifier (majority class) vs. C4.5 algorithm (More details are given in report) 19 Page

Network Behavior of Malware Families: Steps to achieve the goal Log scale plot of incoming and outgoing ratio of packet bytes • Most similar HTTP traffic observed between malware and legitimate traces, from constant packet ratio to varying packet ratio 20 Page

Analysis of Feature Space of Malware (Code Reuse): Steps to achieve the goal Feature Projection to two Dimensional Space using PCA and K-means Clustering • Tbot and Kaiten are close to each other, and form a single cluster. However, Agabot is not as close as the other malware families. Zeus V1, ZeusGameover, ZeusPonyloader, ZeusV2 and Sality form in similar feature range, and most of their instances are assigned to the same clusters 21 Page

Recent papers: • Looks for the multiple source of information i.e., features extracted from not only packets, but also IP addresses, DNS features, HTTP requests etc. ‣ T. Nelms, R. Perdisci, and M. Ahamad. Execscent: Mining for new C&C domains in live networks with adaptive control protocol templates. In Proc. USENIX Security Symposium , 2013 • Focusing on before infection phase, we assume that hosts Steps to achieve the goal are already infected and generates traffic. More challenging... ‣ L. Invernizzi, S.-J. Lee, S. Miskovic, M. Mellia, R. Torres, C. Kruegel, S. Saha, and G. Vigna. Nazca: Detecting malware distribution in largescale networks. In Proc. Network and Distributed System Security Symposium (NDSS) , 2014 • Detection Accuracy is mostly high due to the use of tamper proof features ‣ Port numbers, flags and payload is used 22 Page

Conclusion/Discussion • Presented a framework that evaluates the detection performance of malware heartbeat traffic after blending into legitimate applications • Our framework effectively discriminates most of the C&C heartbeat traffic from legitimate traffic by only using tamper resistant features of transport layer protocol Steps to achieve the goal • We observe substantial decrease in detection with the recent malware families ‣ Malware traffic is disguised in HTTP traffic to conduct an evasion attack • Code reuse is common practice in malware families • Provide a discussion of importance of using tamper resistant feature space, and multiple source of information to alleviate the false negatives by improving the underlying feature space 23 Page

Key Papers Feature Selection: Wei Li, Marco Canini, Andrew W Moore, and Raffaele Bolla. Efficient application identification and the temporal and spatial stability of classification schema, Computer Networks, 2009 Methodology and Insights: F.Kocak, D. J. Miller, and G. Kesidis. Detecting anomalous latent Steps to achieve the goal classes in a batch of network traffic flows. In Proc. Information Sciences and Systems (CISS), 2014 Anomaly Detection Algorithms: V. Chandola, A. Banerjee, and V. Kumar. Anomaly detection: A survey. In ACM Computing Surveys, 2009. State of the art paper in this research area: Gu, R. Perdisci, J. Zhang, W. Lee, et al. Botminer: Clustering analysis of network traffic for protocol-and structure-independent botnet detection. In Proc. USENIX Security Symposium, 2008 24 Page

QUESTIONS Anomaly Detection Algorithms for Malware Traffic Analysis using 25 Tamper Resistant Features
