APPEARANCE PROBABILITY MODEL OF ELECTRON ANTI-NEUTRINOS ACCOUNTING FOR DIFFERENT REACTOR DISTANCES Maria Veronica Prado Advisors: Dr. Glenn Horton-Smith Dr. Larry Weaver KamLAND Experiment 56 nuclear reactors and one detector Detector


  1. APPEARANCE PROBABILITY MODEL OF ELECTRON ANTI-NEUTRINOS ACCOUNTING FOR DIFFERENT REACTOR DISTANCES Maria Veronica Prado Advisors: Dr. Glenn Horton-Smith Dr. Larry Weaver

  2. KamLAND Experiment  56 nuclear reactors and one detector  Detector is located on the island of Honshu, Japan  Each nuclear reactor contains Uranium 235 and 238 & Plutonium 239 and 241  Fission occurs: 57.1% from U 235 7.8% from U 238 29.5% from Pu 239 5.6% from Pu 241

  3. KamLAND Experiment Source: http://kamland.lbl.gov/Pictures/kamland-ill.html

  4. KamLAND Experiment The reactors: n p + e + v e two new elements n after fission reactor with moderator U235 n p + e + v U238 e Pu239 beta Pu 241 decay

  5. KamLAND Experiment The detector: Source: http://kamland.lbl.gov/Pictures/kamland-ill.html

  6. KamLAND Experiment  The Liquid Scintillator inside the detector contains C 9 H 12 (pseudocumene) and C 12 H 26 (dodecane)  Some of the anti-neutrinos coming from the reactors collide with protons found in these molecules  Inverse beta decay

  7. KamLAND Experiment The detector: Gamma photons: 10 keV Optical photons: 1-3 eV Positron moves through the LS losing KE as it ionizes atoms + v + p n + e e Inverse beta Process A decay unstable atom UV/Gamma photon Ionization of atoms γ + e

  8. KamLAND Experiment The detector: A visible photon is Fluorescence emitted from the H molecule The UV photon hits one of the molecules and is γ γ absorbed Optical H photon H DETECTED The visible photon is detected by all the photomultiplier tubes

  9. KamLAND Experiment Meanwhile still in the detector… Go through Process A Gamma _ _ photons e e _ _ γ e e _ _ e e _ + e + e Gamma photons Compton scatter or go through the The positron loses energy DETECTED Photoelectric Effect and comes to a stop where γ _ _ it annihilates with an e e _ _ electron e e _ _ e e Even though there are 3 separate signals in the PMTs, it is detected as only one

  10. KamLAND Experiment Simultaneously in the detector… The neutron bounces off from the + atoms in the LS and moves v + p n + e e slower & slower until it is absorbed Go through Process A Recoil The neutron interacts 2 γ n + p H + with hydrogen (H) from the LS The gamma photon compton (Deuteron) scatters or goes through the photoelectric effect with the atoms in the LS. It produces a detected signal called the 13 n + p C + γ delayed coincidence . Or very rarely

  11. KamLAND Experiment The detector: Source: kamland.lbl.gov/Pictures/picgallery.html

  12. Number of Counts Our main equation:

  13. A simple derivation Flux of the anti-neutrino

  14. A simple derivation where,

  15. Terms The number of counts at each energy prompt The flux of anti-neutrinos expected at the detector Probability that an electron anti-neutrino will stay an electron anti-neutrino by the time it reaches the detector The cross section of one proton that could interact with the anti- neutrinos coming into the detector The number of reactions Probability of detecting a reaction from the reactions that have occurred (due to experimental error)

  16. KamLAND events graph Events graph with what was observed in the detector http://www.awa.tohoku.ac.jp/KamLAND/4th_result_data_release/4th_result_data_release.html

  17. KamLAND appearance probability graph Appearance probability from an average reactor length http://arxiv.org/pdf/1009.4771v2.pdf

  18. Our theoretical research Make a change of variables: P P Q Q N N

  19. Our theoretical research what we want to find empirically For simplicity, we shall call this: We need to minimize for N(Ep): where, N(Ep) has a Poisson distribution because of the rare amount of interactions at the detector

  20. Our theoretical research where, By taking the derivative of and setting it equal to zero, we get transformation of the Q matrix Our observed values

  21. Small proof

  22. Why we want to do this  Prove neutrino oscillations and KamLAND’s conclusions empirically  Gain knowledge about how neutrinos behave, which could lead to a better understanding of dark matter  Gain knowledge about neutrinos to be able to control nuclear reactors efficiently by monitoring neutrinos that leave

  23. Forming the Q matrix For ex: • Test for as many l’s as possible, binning them • If the lies between 1.8 MeV-10 MeV, then plug the values into the Q equation • If the lies outside of that range, it does not contribute to the detector, so we input zero for that matrix element • Obtain a different Q matrix for each reactor • Superpose all the Q matrices

  24. Forming the Q matrix

  25. Our ‘no oscillations’ graph our ‘no oscillations’ graph (without taking into account certain small factors) KamLAND’s ‘no oscillations’ graph

  26. Setting up the test where, appearance probability if there were no oscillations Y Y C C where,

  27. Setting up the test Since, Where R is a matrix containing the orthonormal eigenvectors for each eigenvalue, and D is a diagonal matrix containing all the eigenvalues of C Has the smallest eigenvalue element equal to zero

  28. The Binning Why bin the Ep’s ?  The greater the counts per bin, the smaller the relative error  As a result, approaches a Gaussian Why bin the l’s?  More functions than unknowns  A higher sum in each l column will provide for a smaller error Why find the eigenvalues of C?  If product of eigenvalues is big, error is small when inverting C  If difference is big, magnifies error

  29. Why test it this way  Accounting for bias by using N 0 prime to calculate V inverse instead of N 1 prime: - This method gives each element in N 1 prime their corresponding importance according to how many number of counts they each contribute and, therefore, how much data they contain For example: while

  30. Why omit the smallest eigenvalue? Contains background noise Contains inverse eigenvalues The smaller the eigenvalue, the more noise error it contributes

  31. Error Biggest error contributors:  Background noise in the data N 1 from the experiment  Approximation of l values due to the l binning in Q 0 Producing reasonable error bars for our test of specific P(l)s :  Create N’ 1true with a specific P(l)  Add randomized background noise to N’ 1true  Create 1000 different P(l)s, each using a different randomized N’ 1observed  Find the average P(l) and its standard deviation to obtain different error bars for each P(l) entry

  32. Omitting the smallest eigenvalue 16 Ep bins,11 l bins Smallest error bars so far, but not as small as were expected

  33. Omitting vs not omitting smallest eigenvalue 16 Ep bins,11 l bins Smaller error bars

  34. Testing KamLAND’s N

  35. Comparing Chi Squares Chi square of the N between our estimate and the N observed: 6.68 Chi square of the P between our estimate and the closest straight line of 0.44 without taking into account covariance: 9.65 The above chi square with covariance: 67.95

  36. The Covariance Matrix

  37. Conclusions  Obtained appearance probabilities for 11 values of L/E ν without assuming an average L  Appearance probability cannot be constant  Predicted N matched KamLAND’s observed N

  38. Acknowledgements  Dr. Horton-Smith & Dr. Weaver  Dr. Corwin  KSU HEP Department  Kansas State University  NSF
