802.11n Network Management --- Lara Deek --- Eduard Garcia-Villegas - PowerPoint PPT Presentation

The Impact of Channel Bonding on 802.11n Network Management --- Lara Deek --- Eduard Garcia-Villegas Elizabeth Belding Sung-Ju Lee Kevin Almeroth UC Santa Barbara , UPC-Barcelona TECH , Hewlett-Packard Labs NMSL -


  1. The Impact of Channel Bonding on 802.11n Network Management --- Lara Deek § --- Eduard Garcia-Villegas ‡ Elizabeth Belding § Sung-Ju Lee † Kevin Almeroth § UC Santa Barbara § , UPC-Barcelona TECH ‡ , Hewlett-Packard Labs † NMSL - MOMENT Lab

  2. Channel Bonding (40MHz) 802.11a/b 802.11g 802.11n 802.11ac* IEEE 802.11 1999 2003 2009 2011* Standards Up to 160MHz… 20MHz 20MHz 40MHz Reduction in number of non- Higher transmission rates overlapping channels Greater susceptibility to interference Degradation in transmission range 2 NMSL - MOMENT Lab

  3. Context Related Work Our Work  Operation on 2.4GHz range  Operation on 5GHz range [Shrivastava08] [Pelechrinis10]  Significant opportunities to exploit [Chandra08] channel bonding  Limited opportunities for channel bonding  Extensive study of channel  Insight into characteristics of bonding in real-world network channel bonding settings [Arslan10] [Pelechrinis10] [Chandra08]  Compare 20MHz vs. 40MHz  Identify network settings that impact channel bonding decisions  Signal quality  Strength and transmission rates of neighboring links 3 NMSL - MOMENT LAB

  4. Empirical Study of Channel Bonding  What is the impact of ____ on performance?  Receiver Signal Strength (RSSI)  Rich Scattering Environment  Modulation and Coding Scheme (MCS)  Neighboring nodes  Interference from Channel Leakage  Channel Sharing 4 NMSL - MOMENT Lab

  5. Empirical Study of Channel Bonding  What is the impact of ____ on performance?  Receiver Signal Strength (RSSI)  Rich Scattering Environment  Modulation and Coding Scheme (MCS)  Neighboring nodes  Interference from Channel Leakage RSSI Rx 0  Channel Sharing Tx 0 Tx 1 Rx 1 4 NMSL - MOMENT Lab

  6. Testbed Environment  Node configuration Laptops running Ubuntu 10.04 LTS  802.11n, 2x3 MIMO PC cards with Atheros chipset  Ath9k driver   Measurement environment Semi-open office environment at UCSB  5GHz operation  Controlled environment  Packet aggregation and retransmission disabled  Rate adaptation disabled   Performance metrics Best UDP Goodput  Measured at best transmission rate using exhaustive search  Averaged over multiple runs  5 NMSL - MOMENT Lab

  7. RSSI  What is the impact of RSSI? More accurate decoding of Higher RSSI transmitted signal 6 NMSL - MOMENT Lab

  8. RSSI  What is the impact of RSSI? Lesson 1: Channel Bonding degrades throughput when RSSI is close to minimum input sensitivity. 1 RSSI 1 Rx n Tx Rx RSSI n RSSI < Receiver Minimum Input Sensitivity 6 NMSL - MOMENT Lab

  9. Neighboring Nodes: Channel Leakage  What is the impact of channel leakage? Slower modulation to Power leakage from compensate for error rate Decrease neighboring transmissions SINR due to imperfect hardware Aggressive modulation due to activation of carrier sensing 7 NMSL - MOMENT Lab

  10. Neighboring Nodes: Channel Leakage  What is the impact of channel leakage? Lesson 2: Signal strengths between adjacent transmitters affect channel bonding decisions.  Evaluate impact of channel leakage configurations: 20MHz channel separation 2. Adjacent channels ≥ 40MHz channel 1. 3. separation  Transmitter : Link where performance is evaluated  Interferer: Neighboring link causing interference at the Transmitter link 7 NMSL - MOMENT Lab

  11. Neighboring Nodes: Channel Leakage 1. For the same Interferer configuration, is channel bonding a favorable option? • Yes Channel Bonding Leakage affects a smaller portion of OFDM subcarriers from channel bonding Transmitter Interferer 8 NMSL - MOMENT Lab

  12. Neighboring Nodes: Channel Leakage 1. For the same Interferer configuration, is channel bonding a favorable option? • Yes Channel Bonding Transmitter Interferer 8 NMSL - MOMENT Lab

  13. Neighboring Nodes: Channel Leakage 1. For the same Interferer configuration, is channel bonding a favorable option? • Yes Channel Bonding Transmitter Interferer 8 NMSL - MOMENT Lab

  14. Neighboring Nodes: Channel Leakage 1. For the same Interferer configuration, is channel bonding a favorable option? • Yes 2. What affects the benefits of channel bonding? • Interferer RSSI at Transmitter 8 NMSL - MOMENT Lab

  15. Neighboring Nodes: Channel Leakage 1. For the same Interferer configuration, is channel bonding Strong a favorable option? Transmitter • Yes Strong 2. What affects the benefits of Interferer channel bonding? • Interferer RSSI at Transmitter Channel Bonding Use only 20MHz of free 40MHz in the presence of a neighboring strong Transmitter interferer Interferer 9 NMSL - MOMENT Lab

  16. Neighboring Nodes: Channel Sharing  What is the impact of channel sharing? Multi-rate CSMA nodes Weak/slow nodes sharing the medium penalizing fast stations 10 NMSL - MOMENT Lab

  17. Neighboring Nodes: Channel Sharing  What is the impact of channel sharing? Lesson 3: Knowledge of the transmission rate of neighboring links affects channel bonding decisions.  Evaluate impact of channel sharing configurations: Partial overlap Complete overlap 1. 2.  Transmitter : Link where performance is evaluated  Interferer: Neighboring link causing interference at the Transmitter link Strong Interferer, fast transmission rates 1. Weak Interferer, slow transmission rates 2. 10 NMSL - MOMENT Lab

  18. Neighboring Nodes: Channel Sharing 1. Which bandwidth do we prefer to compete with? • 40MHz Transmitter Link Competing with a 20MHz interferer Competing with a 40MHz interferer 40MHz achieves higher rates thus alleviating Interferer fairness issues Transmitter 11 NMSL - MOMENT Lab

  19. Neighboring Nodes: Channel Sharing 1. Which bandwidth do we prefer to compete with? • 40MHz Transmitter Link Competing with a 20MHz interferer Competing with a 40MHz interferer 40MHz achieves higher rates thus alleviating Interferer fairness issues Transmitter 11 NMSL - MOMENT Lab

  20. Neighboring Nodes: Channel Sharing 1. Which bandwidth do we prefer to compete with? • 40MHz Transmitter Link Competing with a 40MHz interferer Best performance 40MHz achieves higher rates thus alleviating Interferer fairness issues Transmitter 11 NMSL - MOMENT Lab

  21. Neighboring Nodes: Channel Sharing 1. Which bandwidth do we prefer to compete with? • 40MHz 2. For the same Interferer configuration, is channel bonding a favorable option? • Yes Transmitter Link Channel Bonding Competing with a 20MHz interferer Competing with a 20MHz interferer Interferer Transmitter 11 NMSL - MOMENT Lab

  22. Neighboring Nodes: Channel Sharing 1. Which bandwidth do we prefer to compete with? • 40MHz 2. For the same Interferer configuration, is channel bonding a favorable option? • Yes Transmitter Link Channel Bonding Competing with a 40MHz interferer Competing with a 40MHz interferer Interferer Transmitter 11 NMSL - MOMENT Lab

  23. Neighboring Nodes: Channel Sharing 1. Which bandwidth do we prefer to compete with? • 40MHz 2. For the same Interferer configuration, is channel bonding a favorable option? • Yes Transmitter Link 3. What affects the benefits of channel bonding? • Interferer transmission rate 11 NMSL - MOMENT Lab

  24. Neighboring Nodes: Channel Sharing For the same Transmitter, Test Case 1: Interferer good link quality ( fast transmission rate) Test Case 2: Interferer poor link quality ( slow transmission rate) Competing with a 40MHz interferer Competing with a 40MHz interferer Channel Bonding Test Case 1: Performance improves Test Case 2: Performance benefits diminish due to lower rates at the Interferer Interferer Transmitter 12 NMSL - MOMENT Lab

  25. Summary of Lessons Learned  Lesson 1: Signal strength at receiver (RSSI)  Lesson 2: Strength of interfering transmissions  Lesson 3: Transmission rates of links in CS range RSSI Tx 0 Rx 0 Tx 1 R x Rx 1 13 NMSL - MOMENT Lab

  26. Evaluation of Lessons Learned  Create network scenarios and compare the impact of:  Naïve decisions  Assign channel with weakest interfering signal  Intelligent decisions  Rely on lessons learned to assign channel  Evaluation environment  Limit available channels to recreate contention for bandwidth  Replicate off-the-shelf wireless devices  Enable frame aggregation  Enable automatic rate selection 14 NMSL - MOMENT Lab

  27. Evaluation of Lessons Learned (cont’d)  Transmitter “T” requesting bandwidth: Leakage from CH 48 Naïve approach Intelligent approach 15 NMSL - MOMENT Lab

  28. Evaluation of Lessons Learned (cont’d)  Transmitter “T” requesting bandwidth: Low rate on CH 52+56 Naïve approach Intelligent approach 15 NMSL - MOMENT Lab

  29. Evaluation of Lessons Learned (cont’d)  Transmitter “T” requesting bandwidth: 1.15 × High rate CH 36+40 & Low Leakage CH 44 7 × Naïve approach Lessons allow for intelligent decisions that leverage the Intelligent approach benefits of channel bonding in typical 802.11n environments 15 NMSL - MOMENT Lab
