7 th CAPSA 99: General Session 5: Innovation in Asphalt Pavement - PowerPoint PPT Presentation

7 th CAPSA 99: General Session 5: Innovation in Asphalt Pavement Design Towards Improved Mechanistic Design of Thin Asphalt Layer Surfacings based on Actual Tyre/Pavement Contact Stress - In - Motion (SIM) data in South Africa Morris De Beer


  1. 7 th CAPSA ’99: General Session 5: Innovation in Asphalt Pavement Design Towards Improved Mechanistic Design of Thin Asphalt Layer Surfacings based on Actual Tyre/Pavement Contact Stress - In - Motion (SIM) data in South Africa Morris De Beer (CSIR) Louw Kannemeyer (SANRA Ltd) Colin Fisher (CSIR)

  2. 7 th CAPSA: ‘99 Stress - In - Motion (SIM) Technology IR , Transpo tek , South CSIR portek h Africa ca

  3. Stress – In – Motion (SIM) Technology = The measurement of 3D tyre/pavement contact stresses from moving vehicles

  4. MACRO-CLIMATE: SOUTH AFRICA North & MAJOR ROAD SYSTEM DRY DRY N1 # Botswana N1 # N4 # # N17 Namibië N14 MODERATE MODERATE # N11 DRY DRY # N3 DRY # N1 DRY N14 # # # N12 N10 N5 # WET # WET N14 # DRY DRY # N14 N12 # DRY N10 DRY # # N1 # N6 Durban # N2 West N7 N12 WET # # WET N10 # # N10 Coast East MODERATE MODERATE R12 # N1 N9 # # Coast # WET N2 WET # Capetown N2

  5. Surfacing Types of National Roads in South Africa (1997/8) CRCP (0,5%) PCC (7,5%) Chip & Spray HMA Seals (46,3%) (45,6%)

  6. Base and Subbase Types G1/G2 Base on Stab Subbase (29%) of National Roads in G1/G2 Base on Nat gravel South Africa (1997/8) Subbase (27 %) HMA (13 %) 3% 6% 6% 29% PCC (9 %) 7% C3/C4 Base on Nat gravel HMA Subbase (7 %) 9% C3/C4 Base on Stab gravel Subbase (6%) G3/G4/G5 Base on Nat 13% Gravel Subbase (6%) 27% G3/ G4/ G5 o n Stab Subbase (3%)

  7. RUTTING

  8. Longitudinal Flow of Asphalt

  9. Longitudinal Flow of Asphalt

  10. Fatigue Cracking and aging

  11. SURFACE DISINTEGRATION

  12. How to address the problem?? SIM Technology: Vehicle-Road Surface Pressure Transducer Array (VRSPTA)

  13. 315/80 R22.5 HVS TYRE ON VRSPTA

  14. 425 /65 R22.5 HVS TYRE ON VRSPTA

  15. VRSPTA Mark III

  16. VERTICAL CONTACT STRESS: VARIABLE LOADING (315 TIRE)

  17. LATERAL CONTACT STRESS: (Across 315 TIRE)

  18. LONGITUDINAL CONTACT STRESS: (Along 315 Tire)

  19. TYRES

  20. Tyre Inflation Pressure in South Africa: Increase: ~20 % in 20 Years

  21. Tyres: Heavy vehicles: Axle Loads > 7 000 kg Survey: 1995 1.2% 9.7% 13.8% 38.5% 3.6% 33.2% 9.00-11.00-20 11.00-R20 11.00-R22.5 12.00-R22.5 275/80-315/80 R22.5 385/80-445/65 R22.5 Distribution of heavy truck tyre types in South Africa

  22. NOMINAL DISTRIBUTION OF TRUCK TYRE TYPES IN SOUTH AFRICA (1995/6) (25.5%) <11-R22.5 (38.0%) 12.00-R22.5 (3.6%) Wide Base (32.9%) Wide Duals

  23. TYPI PICAL CAL CO CONT NTACT ACT STRESS ESS DA DATA

  24. Tyre Load = 18 kN 1600 INFLATION PRESSURE:: CONTACT STRESS (kPa) 1400 420 kPa 520 kPa 620 kPa 720 kPa 1200 Tyre width: 220 mm 1000 800 600 400 200 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 PIN NUMBER ACROSS VRSPTA FIGURE 11 Maximum vertical stress at CONSTANT LOAD and various inflation pressures

  25. Tyre Load = 49 kN 1600 Tyre width: 220 mm CONTACT STRESS (kPa) 1400 1200 1000 800 600 400 INFLATION PRESSURE: 200 420 kPa 520 kPa 620 kPa 720 kPa 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 PIN NUMBER ACROSS VRSPTA FIGURE 12 Maximum vertical stress at CONSTANT LOAD and various inflation pressures

  26. INFLATION PRESSURE = 420 kPa 1600 CONTACT STRESS (kPa) WHEEL LOAD: 1400 20kN 30kN 40kN 50kN 1200 1000 800 600 400 200 Tyre width: 220 mm 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 PIN NUMBER ACROSS VRSPTA FIGURE 13 Maximum vertical stress at CONSTANT INFLATION PRESSURE at various loads

  27. INFLATION PRESSURE = 620 kPa 1600 WHEEL LOAD: CONTACT STRESS (kPa) 1400 20kN 30kN 40kN 50kN 1200 1000 800 600 400 200 Tyre width: 220 mm 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 PIN NUMBER ACROSS VRSPTA FIGURE 14 Maximum vertical stress at CONSTANT INFLATION PRESSURE and various loads

  28. Tyre Load = 20 kN TYRE INFLATION PRESSURE: CONTACT STRESS (kPa) 420 kPa 520 kPa 620 kPa 720 kPa 1600 1400 1200 1000 800 600 400 200 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 PIN NUMBER OF VRSPTA Maximum vertical stress of tyre with tread grooves at CONSTANT LOAD and various inflation pressures

  29. INFLATION PRESSURE = 520 kPa CONTACT STRESS (kPa) 1600 1400 TYRE LOAD (kN): 1200 42 1000 30 800 26 600 20 400 15 200 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 PIN NUMBER OF VRSPTA Vertical stress of tyre with tread grooves at CONSTANT INFLATION PRESSURE and various loads

  30. 4 PA 4 PAD D SI SIM SYS M SYSTE TEM M

  31. VRSPTA Mark III

  32. Deflectograph Truck (80kN, 650 kPa): Vertical Contact Stress

  33. Deflectograph Truck (80kN,650 kPa): Lateral Contact Stress

  34. Deflectograph Truck (80kN,650 kPa): Longitudinal Contact Stress

  35. DEFLECTOGRAPH (OCTOBER 1998) Test 038-z 100 % Cumulative Frequency 80 60 40 690 kPa (Rear) 20 600 kPa (Front) 520 kPa (Design) 0 0 200 400 600 800 1000 1200 Measured Tire Contact Stress (kPa) Tyre Front Left Front Right Rear Left OuterRear Left Inner Rear Right Outer Rear Right Inner Inflation Pressure 600 kPa 600 kPa 690 kPa 690 kPa 690 kPa 690 kPa

  36. G D A E S 1 0 PERCENTAGE REDUCTION (%) GRANULAR GR ANULAR BA BASE E PA PAVEM EMENT ENT 120 100 AG 80 G2 60 C 3 SG7 40 SG9 20 0 400 600 800 1000 500 700 900 1100 VER TIC AL C ONT ACT ST R ESS (kPa)

  37. B A E S 3 PERCENTAGE REDUCTION (%) BITUMEN BI UMEN BA BASE E PA PAVEM EMENT ENT 35 30 AG 25 BC 20 C4 15 SG7 10 SG9 5 0 400 600 800 1000 500 700 900 1100 VERTICAL CONTACT STRE SS (kPa)

  38. MANTSOLE TRAFFIC CONTROLL CENTRE (TCC) ON NATIONAL ROAD NR 1 (N1) Full Axle SIM North

  39. WEIGH - BRIDGE SITE FOR SIM AT MANTSOLE ON THE N1

  40. MANTSOLE TCC

  41. TRUCK IDENTIFICATION INCLUDES:  Vehicle Registration number;  Date of measurement;  Time of measurement;  Vehicle classification (i.e 1:2:2:2)  Tyre inflation pressure and tyre temp only on selected trucks at the TCC.

  42. The following items are obtained with the SIM:  Axle Speed;  Axle Distance;  Axle weights;  Axle Group weights;  Tyre width;  Tyre contact area;  Tyre patch length (TPL);  Tyre weights;  3D Vertical, Lateral & Longitudinal Stresses;  Stress Ratios;

  43. SIM TESTS: BREAK DOWN OF VEHICLE CLASSES MEASURED (MANTSOLE, N1) (5.6%) (19.4%) 1:1 1:1:2 (2.8%) (33.3%) 1:2:2 1:2:3 1:2:2:2 (16.7%) 1:2:3:2 (22.2%)

  44. MANTSOLE WEIGHBRIDGE (TCC) SIM TESTS NOV. & DEC. 1998 & FEB 1999 SIM LOADCELLS (Tonne) 30 20 10 0 0 5 10 15 20 25 30 35 MULTI-DECK (Tonne) 1 to 1 Regression line (Rsqr = 0,956) Validated Data (26 Trucks) MAN1.WK4

  45. AXLE 5 Vertical Maximum Contact Stress (kPa) 1200 1000 Stress (kPa) 800 600 400 200 0 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39 41 42 40 38 36 34 32 30 28 26 24 22 20 18 16 14 12 10 8 6 4 2 Pin numbers 001-z DMB 453 GP Left Outer Left Inner Right Inner Right Outer Tyre Tyre Tyre Tyre

  46. MANTSOLE TESTING (NOV 98) FILE 001-Z (COMBINATION 1 2 2 2) % Cumulative Frequency 100 90 80 70 60 50 40 30 20 10 0 0 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 Contact Stress (kPa) CUM-001.WK4 DMB 453 GP ax1l ax1r ax2l ax2li ax2ri ax2r ax3l ax3li ax3ri ax3r ax4l ax4li ax4ri ax4r ax5l ax5li ax5ri ax5r ax6l ax6li ax6ri ax6r ax7l

  47. Summary of SIM data: Mantsole, TCC on N1:  SIM Data of 36 trucks - 704 tyres analyzed;  SIM Accuracy vs Multi-deck Scale: within 2,5 %;  SIM Precision @ 95 % = 2,6 tonne /Axle Group;  Vertical Stress: 577 – 1149 (Ave. = 903 kPa);  Lateral Stress: 89 – 233 (Ave. = 170 kPa);  Longitudinal Stress: 52 – 237 (Ave. = 124 kPa);

  48. Summary of SIM data: Mantsole, TCC on N1 Continue:  Stress Ratios: 10:1,88:1,38  Average Max Vertical > 1,59 x Inflation Pressure;  Max Vertical Stress/520 kPa : 1,37 to 2,75 (NCP);  Vertical Stress Patterns of approx. 22 % of tyres show “abnormal” patterns;

  49. Radial Distance (mm) 1 300 600 100 0 Non-Uniform Vertical Stress C L Tyre Edge Depth (mm) Lateral stress 0 40 200 1 300 FIGURE: 29 Axi-symmetrical Finite Element Model used in this study

  50. Pseudo-Energy under non-uniform contact stress conditions (Symplectic Engineering Corporation, USA)

  51. Colour maps of Shape distortion (Symplectic Engineering Corporation)

  52. Summary & Conclusions: • SIM Technology proven to be successful locally and overseas; • Ratio of Stresses: Vert : Lat : Long = 10 : 2 : 1,5 • SIM results useful to Civil Engineers and road building; • Challenge to develop detailed design and analyses methods utilizing SIM data; • Finite Element Analysis Methods (FEM) to be used more widely with SIM data in road design; • SIM systems should be improved for wider use such as “WIM”;

  53. I Thank You all !!
